70 mm / 2.75 in (CLR 80 mm) Y-Pipe Bend Cutting Template STL – Exhaust Merge Fabrication Jig

Digital 3D printable Y-PIPE BEND CUTTING TEMPLATE for fabricating a custom exhaust Y-pipe from Ø70.0 mm round tubing. This version is designed for one specific bend geometry: TUBE OUTSIDE DIAMETER: Ø70.0 mm Imperial reference: Approximately 2.75 in BEND CENTERLINE RADIUS: CLR 80 mm Imperial CLR reference: Approximately 3.15 in 70.0 mm ≈ 2.75 in 80.0 mm ≈ 3.15 in The exact dimensional references for this model are: Ø70.0 mm tube OD CLR 80 mm BEND RADIUS IS IMPORTANT: Exhaust bends with the same…
