V8 training engine model kit 265 mm - working valvetrain, 16 moving valves, cutaway, no supports

A 265 mm V8 made for explaining how an engine works. Turn the flywheel: the crankshaft drives the camshaft through 22:44 timing gears, 32 cam lobes move 16 lifters, pushrods and rockers, and every valve opens and closes at the right moment while the eight pistons run. The left side is cut open - window in the block, cylinder head in section, rocker cover and timing cover open - so you can follow intake, compression, power and exhaust stroke by stroke. ## Dimensions (measured on the CAD solid) |…
