Ventilation duct 125 mm (DN125), 200 mm long – round air duct pipe, spigot ends, no supports

200 mm of round duct, nominal size 125 mm. Both ends are spigots; the matching sockets sit on the couplers, socket ducts, elbows and reducers of the same range. **Picture 1:** multi-view drawing with all dimensions and cross-sections. **Picture 2:** the part as a render. **Picture 3:** a section view. ## Dimensions (mm, measured on the CAD solid) | Dimension | Value | |---|---| | Nominal size (outside of the spigot) | 125 mm | | Inside diameter | 119 mm | | Wall | 3 mm | | Free cross-section |…
