Three-spoke handwheel for Knurled shaft 6 mm, 40 teeth - 4 sizes 25/30/36/44 mm, no supports

Three-spoke handwheel for Knurled shaft 6 mm, 40 teeth - 4 sizes 25/30/36/44 mm, no supports

AMPERELAB3D · Cults3D

$1,11CULTS PU - Private Use

Three spokes, three big windows. The lightest wheel in the library, and the easiest to grip through with a finger. For the fine 40-tooth knurled 6 mm shaft. Four manufacturers dimension this one identically: 6.0 mm over the teeth, knurl 7 mm long. Press-fit. ## Sizes in the download All 4 diameters, same shaft fitting: | Diameter | Height | Volume | Weight in PETG | |---|---|---|---| | 25 mm | 16.6 mm | 3.0 cm³ | 3.8 g | | 30 mm | 16.6 mm | 3.9 cm³ | 4.9 g | | 36 mm | 16.6 mm | 5.2 cm³ | 6.6 g…

♥ 0

Cults3D'da aç
#control knob#knob#three-spoke handwheel#6mm shaft#40 spline#40 teeth#knurled shaft#potentiometer#rotary encoder#amplifier#mixing desk#synthesizer
